192 Core Inline Underground Fiber Splice Enclosure TSB-104A

Publisher: MJADOM

Author: Andy

Underground Fiber Splice Enclosure also called Fiber Enclosure, It made of Modified P.P and has a new gasket seal making them ideal for a wide variety of applications.


MJADOM offers Fiber Optic Splice Closure (Aerial / Pole Mount / Underground, Heat Shrink Sealing / Mechanical Sealing, 24-576 Fibers, LC/SC adapter, Protective Level IP68, 1x8/1x16 PLC Splitter).

The Underground Fiber Splice Enclosure

The underground fiber enclosure (RGP-TSB-104A) is made of plastic molded parts and gasket sealing materials. It's a Mechanical Gel Sealing type FOSC, which can adopt 6 Round Port design for 3 inlets & 3 outlets.

The sliding latching mechanism can simply do the closing of the closure. The latching system provides a short installation time and it can be easy to re-enter. There is no need for special tooling to close or open the closure.



The underground splice enclosure is suitable for up to 12 single fibers, which can cover most of the applications in the fiber distribution networks like Fiber To The Home / Fiber To The Curb (FTTH/FTTC) Under-ground, aerial, pedestal or direct buried applications are possible with the closure.


How to splice underground cable

Underground fiber splicing is a very common task. It involves connecting two different types of cables together. This is done by pulling out the old cable, cutting off the ends, then inserting the new cable into the cut end. Once the connection is made, the ends need to be sealed so they don't leak.


Product Description:

Underground Fiber Splice is an innovative fiber splicing enclosure designed specifically for underground fiber optic splices. This product is used to protect spliced fibers during installation, maintenance, and repair.

Features:

1. Protects spliced fibers from damage caused by sharp objects, dirt, moisture, etc.

2. Provides protection against mechanical shock and vibration

3. Prevents dust and debris from entering the splice area

4. Allows access to spliced fibers for inspection and testing

5. Can be installed in either direction

6. Has a unique gasket design that provides superior sealing performance

7. Available in various sizes

Benefits:

1. Protect spliced fibers from damage

2. Provides protection from mechanical shock and vibration


Closure Material : MPP-Modified P.P.

Closure Seal Material : Vualcanized silicone rubber.

May be used for cut, uncut and taut sheath applications.

May be used for all fiber optic cable.

Sheath retention & central strength member fasten system included.

Ribbed closure construction and lightweight plastic provides strength and resistance to chemical and U.V attack.



Sliding latch mechanism.

Compatible with most common cable types: e.g. Loose tube, central core, slotted core, ribbon fiber.

It applies to multiple environments ( Underground, Aerial, Pole, Bracket, Pipe-lined, Manhole.).

Protection class: IP68.

RoHS compliance.

Reusable & Re-entry Test.


Aerial mounting.

Under-ground.

Pedestal or direct buried applications.


Configuration

Standard Accessories:

ItemNameUsageQuantity
1Splice cassetteTo splice the fiber opticSame as capacity
2Fiber Splice Protective SleevesTo protect fiber splicesSame as capacity
3Nylon TieTo fix buffer tubes with fibers insideSame as capacity
4Grounding WireTo connect with grounding device1pc
5Abrasive ClothTo polish fiber optic cable1pc
6Labelling PaperTo label fibers1 set
7Buffer TubeTo protect fibers and be fixed on splice trays1pc
8Installation bolts and nutsTo fix splice cassette1 set


Shipping Infomation

SpecificationSizePcs/CartonWeight
Internal Carton Box460mmx225mmx170mm1 pc4.1 KGS
Outside Carton Box470mmx450mmx515mm6 pcs24.5 KGS


Order Information:

Model No.Splice TraySpliced fiber storage capacitySize(mm)LxWxHCable portsMax. diameter of cable(mm)
RGP-TSB-104A

Tray 305D1

Capacity : 12 splices

96 Splices

(8x12 Splices)

450mmx216mmx160mm6 round ports

6 ports : 2 ports, each port for 1 cable with max 23 mm.

2 ports, each port for 1 cable with max 20 mm.

2 ports, each port for 1 cable withmax 16 mm.

192 Splices

(8x24 Splices)
