Description:
RGP-F2E-506F-8R 8 Ports Pre-Connectorized Optical Fiber Distribution Box provides a high-density wall-mounted & aerial mounted solution for the next generation networks, which aims to provide and manage maximum numbers of fiber termination in a limited space. Pre Connectorized ODN Junction Box features with ruggedness, which is tested under harsh conditions and stand up to even the most severe conditions of moisture, vibration and extreme temperatures.
Pre-Connectorized Solution Nap Box can be used for FTTH deployments (PON and P to P networks) as well as for use with high fiber and city center deployments.
Feature:
Material: Modified P.P.
Sealing Structure: Mechanical Sealing.
Closure Seal Material: Thermoplastic rubber.
180-degree access with buckled lock structure
Dis-mountable adaptor panel, Support mid-span termination.
Rotatable and dis-mountable splice tray for easy splicing.
Integrated with flap-up splice cassette and cable management system.
Plug-and-play installation, easy for maintenance and expansion, Integrated with flap-up splice cassette and cable management system.
Manage fibers in a reasonable fiber radius condition, Fiber bend radius control more than 40mm.
The upper cover can install 8 pcs Pre-Connectorized Connector, the lower layer can install 1 pc 24F splice trays, easy for future expansion and maintenance.
6 cable ports entrance, 2 for feeder cable (8-20mm) and 4 for branching cable, 8 Ports pre-connectorized drop cable entrance for SC Pre Connectorized Connector.
Impact test:1K10. Pull Force:100N. Full Rugged design.
Support ADSS cable and self-support fiber cable.
Can accommodate two 1x5 Unbalance Fiber Splitter;
Protection class: IP65.
RoHS compliance.
Applications :
Wall mounting & Aerial mounting installation.
