Description:
The SFP-BIDI Fiber Optic Transceivers Module also called SFP Gpon Module or SFP Optical Module or 1550 SFP or SFP Module 1310nm, It's high-performance, cost-effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps with SMF. The transceiver consists of three sections: a FP laser transmitter, aPIN photodiode integrated with a trans-impedance preamplifier (TIA), and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
The 1000BASE-BX SFP optics provide 10km high-speed data links using a single strand of fiber, which can upgrade transmission capacity very conveniently without installing new fibers. The SFP transceiver module is a Class 1 laser product that complies with FDA/CDRH and IEC-60825 standards.
MJADOM offers a full range of fiber optic transceivers include Cisco 1000BASE BIDI SFP, wavelength 1310nm/1490nm/1550nm,100% Cisco Compatible, 10km~120km, LC, DDM module transceiver. Buy High-Performace Original Cisco fiber transceiver from reliable fiber optic supplier-MJADOM.COM
Features:
Single Mode Bi-directional Transmission.
Up to 1.25Gbps Data Links.
Wavelength: 1310/1490/1550nm.
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle.
Compatible with SONET OC-24-LR-1.
Compliant with IEEE 802.3z.
Digital Diagnostic Monitoring: Internal or External Calibration.
Build-in WDM.
Simplex LC connector.
+3.3V single power supply.
ROHS compliant and Lead-Free.
Operating case temperature:Standard : 0 to +70°C,Extended : -40 to +85°C.
Production Specification:
| Item Model | 1.25G-BIDI SFP | Name | Specification |
| Form Factor | SFP | Max Data Rate | 1000Mbps |
| Wavelength | 1310nm-TX/1550nm-RX | Max Cable Distance | 10km |
| Connector | LC Simplex | Optical Components | FB BiDi |
| Media | SMF | DOM Support | Yes |
| TX Power | -9~3dBm | Receiver Sensitivity | < -23dBm |
| Commercial Temperature Range | 0 to 70°C | Protocols | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant |
Applications:
Gigabit Ethernet.
Fiber Channel.
Switch to Switch interface.
Switched backplane applications.
Router/Server interface.
Other optical transmission systems.
